Model: YA-D3-4
Overall Size: 2130*970 *350-650mm
Safe Working Load: 175kg
Functions: Backrest adjustable, Footrest adjustable, High-Low
Color options: Green, Blue, Wood
Motor: Jiechang motor
Warranty： 3-Year on Frame and Welds, and 1-Year on Parts
After-sale Service: Online technical support
Customization: Available
Certificate: CE / ISO
Main features
- Ultra-Low bed
- 3 movements electrical operation
- Collapsible aluminum railing with 6 bars
- Hand remote control
- Detachable head/footboard with easy lock
- Caster diameter of 125mm with diagonal locking
- Bumper caster on four corners
- Auto-counter to provide the patient from sliding onto foot end
Accessories
- IV stand
- Urine bag hook
- Hand remote controller
Technical parameter
| Model | YA-D3-4 |
| Overall size（L*W*H） | 2130*970 *350mm (83.8″ x 38.1″ x 13.7″) |
| Lying size | 1880*830 mm (74″ x 32.6″ ) |
| Back section up/down | 0-75° |
| Foot section up/down | 0-40° |
| Height adjustment | 350-650mm (13.7″ – 25.5″ ) |
| Safe loading capacity | 175kg（385 Ibs） |
